Description
| WIRELESS | |
|---|---|
| Standards | Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz Bluetooth 4.2 ZigBee HA 1.2 |
| WiFi Speeds | AC2200 5 GHz: 867 Mbps (802.11ac) 5 GHz: 867 Mbps (802.11ac) 2.4 GHz: 400 Mbps (802.11n) |
| WiFi Range | 4-6+ Bedroom Houses (3-pack)
TP-Link Mesh Technology 8× Antennas (Internal) Beamforming |
| WiFi Capacity | Medium
Tri-Band 4×4 MU-MIMO |
| Working Modes | Router Mode Access Point Mode |
| HARDWARE | |
|---|---|
| Processor | Qualcomm 717 MHz Quad-core CPU |
| Ethernet Ports | 2× Gigabit Ports
*Per Deco Unit |
| Buttons | Reset Button |
| SECURITY | |
|---|---|
| WiFi Encryption | WPA-Personal WPA2-Personal |
| Network Security | SPI Firewall Access ControlHomeCare™ Antivirus Malicious Site Checker |
| Guest Network | 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
| SOFTWARE | |
|---|---|
| Protocols | IPv4 IPv6 |
| Service Kits | HomeCare™ Learn More>Smart Hub Compatible Smart Product> |
| Parental Controls | HomeCare™ Parental Controls
Custom Profiles |
| WAN Types | Dynamic IP Static IP PPPoE PPTP L2TP |
| Quality of Service | HomeCare™ QoS
QoS by Device |
| Cloud Service | OTA Firmware Upgrade TP-Link ID DDNS |
| NAT Forwarding | Port Forwarding UPnP |
| IPTV | IGMP Proxy IGMP Snooping Bridge Tag VLAN |
| DHCP | Address Reservation DHCP Client List Server |
| DDNS | TP-Link |
| Management | Deco App |
| PHYSICAL | |
|---|---|
| Dimensions (W×D×H) | 5.7 × 5.7 × 1.8 in (144 × 144 × 46 mm) |
| Package Contents | Deco M9 Plus (3-pack) 3 Deco M9 Plus Units 1 RJ45 Ethernet Cable 3 Power Adapters 1 Quick Installation GuideDeco M9 Plus (2-pack) 2 Deco M9 Plus Units 1 RJ45 Ethernet Cable 2 Power Adapters 1 Quick Installation GuideDeco M9 Plus (1-pack) 1 Deco M9 Plus Unit 1 RJ45 Ethernet Cable 1 Power Adapter 1 Quick Installation Guide |
| OTHERS | |
|---|---|
| System Requirements | Android 4.4 or later iOS 9.0 or later |
| Certifications | CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS |
| Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| TEST DATA | |
|---|---|
| WiFi Transmission Power | CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) FCC: <30 dBm |
